The TR-Mark III 250V is a three phase transformer turns ratio meter with a test voltage measurement range of up to 250V.

The TR-Mark III 250V transformer turns ratio meter offers new features and increased accuracy to make it a perfect system. A color LCD with a backlight and a touch screen increases handling and user comfort. Two USB interfaces make it easy to store measurements on external storage devices, to transfer easily to a personal computer, or download nameplate data of the transformer to test.

Drivers Library To find the latest driver for your computer we recommend running our Free Driver Scan. Speakers / Headphones (Realtek Audio) - Driver Download. This driver package provides the necessary installation files of Realtek AC97 Audio Driver 6.0.1.6303 for Vista/Windows 7. If you already installed a previous version of this driver, we recommend upgrading to the last version, so you can enjoy newly added functionalities or fix bugs from older versions.

  • Extended test voltage measurement range of up to 250V
  • Automatic measurements of voltage, turns ratio, current, and phase displacement
  • Easy one-time hook up to the transformer
  • Automatic test voltage range
  • Displays deviation from a nominal ratio
  • Tap changer interface with graphic results
  • Load on test object <0.05 VA
  • Measures power transformers PTs and CTs
  • Automatic vector group detection
  • Displays % error vs. name plate value
  • Enhanced heavy-duty protection circuitry
  • Emergency stop push button immediately turns off output
  • Internal printer
  • Data storage of over 10,000 measurements
  • Simple-to-operate color LCD touch screen with backlight
  • Two USB interfaces
  • 5-Year standard warranty
RangeAccuracy at 100V or 40VAccuracy at 10VResolution
0.8 … 2,000±0.06% Rdg ±1 LSD±0.15% Rdg ±1 LSD5 Digits
2,001 … 4,000±0.1% Rdg ±1 LSD±0.3% Rdg ±1 LSD5 Digits
4,001 … 13,000 ±0.3% Rdg ±1 LSDnot specified5 Digits
13,001 … 16,000±0.4% Rdg ±1 LSD5 Digits
RangeAccuracy at 250VResolution
0.8 … 5,000±0.06% Rdg ±1 LSD5 Digits
5,001 … 10,000±0.1% Rdg ±1 LSD5 Digits
10,001 … 32,500±0.3% Rdg ±1 LSD5 Digits
32,501 … 40,000±0.4% Rdg ±1 LSD5 Digits
CurrentAccuracyResolution
0 … 1A±0.001A0.1mA
Phase AngleAccuracyResolution
±90 Degree ±0.05 Degree 0.01 Degree
Turns Ratio Range 0.8 to 40,000
Temperature Operating: -10ºC to 60° C (14°F to 140°F)
Storage: -20°C to 70°C (-4°F to 158°F)

See Instruction Manual for more Parameters. Specifications subject to improvement at any time.

Intel® Z490 (LGA 1200) ATX motherboard features dual M.2, USB 3.2 Gen 2 Type-C®, Thunderbolt™ 3 support, Intel® 2.5 Gb Ethernet. Prime Z490-A caters to daily users and all-round builders looking for well-rounded specs with a wealth of options for performance tuning via intuitive software and firmware features. The Raytek Raynger MX2 has a temperature range of -25 to 1600°F (-30 to 900°C). Infrared thermometers from the Raytek Raynger MX2 Series have many applications. Use your Raynger MX2 infrared thermometer to check for hot spots in electrical panels, circuit breakers, generators, and gearboxes. The TR-Mark III 250V is a three phase transformer turns ratio meter with a test voltage measurement range of up to 250V.

  • Size L: 470 mm (18.5″) W: 371 mm (14.6″) H: 190 mm (7.5″)
  • Weight: 10.2 kg (22.4 lbs.)
  • Input Power: 100 to 250 VAC, 50/60 Hz auto ranging. Fuse: 2A
  • Test Voltage: User Selectable: 250, 100, 40, 10, and 1VAC
  • Max. Test Current: 1A
  • 5.7″ Panel Display Color LCD with a backlight and touch screen
  • Front Panel: Sealed, anodized
  • Interface: 2 USB 2.0 (1 host/1 device) and 9 Pin RS-232 serial
  • Memory Storage: Internally stores more than 10,000 test results
  • Temperature: Operating: –10°C to 60°C (14ºF to 140ºF), Storage: –20°C to 70°C (-4ºF to 158ºF)

See Instruction Manual for more Parameters. Specifications are subject to change without notice.

  • 1002A-05015: H and X Lead Set – 5m (16ft.), 4.1cm (1.6 in.) jaw opening
  • 1002A-05023: Red Extension Lead Set (2) – 10m (32 ft.)
  • 1002A-07001: Power Cord – 6.09m (20 ft.)
  • 1011A-05013: Ground Lead – 5m (16ft.)
  • 1003A-37001: A-B USB Cable – 3m (10ft).
  • 2020A-23001: RS-232 Cable – 3m (10ft.)
  • 1004A-27003: External USB Drive
  • 2040A-08003: Touch Screen Stylus
  • 1002X-07001: Spare Fuse Set, Time Delay 2A (Qty. 5)
  • 2040A-03004: Cable Bag with Shoulder Strap
  • 2040X-18002: Paper Refill for Printer – 5 rolls
  • 1003A-02002: Instruction Manual
  • 1004X-10001: Certificate of Accuracy
Raytek
  • 1003N-31001: External Trigger Switch for Tap Changer Testing — 10m (32 ft.)
  • 1002A-05002: Red Extension Cable – 10m (32 ft.)
  • T-Rex: 3 Phase Test Voltage Option for TR-Mark III and TR-Mark III 250V
  • TR-Mark III R 250V: 19″ 4U Rackmount version
  • 1004N-15002: Annual Warranty Extension

Firmware TR-Mark III (3.2.0.0)
