Old Sensable Phantom Omni on Windows 10. I also have tried to changing the 1394 PCIe interface to use the Legacy driver as mention in this blog https. Side note: The IPv4-over-1394 drivers of Mac OS X 10.4, Windows XP SP3, and the Thesycon 1394 bus driver for Windows all use the middle address space too.

-->

Windows 7 includes 1394ohci.sys, a new IEEE 1394 bus driver that supports faster speeds and alternative media as defined in the IEEE-1394b specification. The 1394ohci.sys bus driver is a single (monolithic) device driver, implemented by using the kernel-mode driver framework (KMDF). The legacy 1394 bus driver (available in earlier versions of Windows) includes multiple device drivers that were implemented by using the Windows Driver Model (WDM) in a port/miniport configuration. The 1394ohci.sys bus driver replaces the legacy port driver, 1394bus.sys, and the primary miniport driver, ochi1394.sys.

The new 1394ohci.sys bus driver is fully backward compatible with the legacy bus driver. This topic describes some of the known differences in behavior between the new and the legacy 1394 bus driver.

Note

The 1394ohci.sys driver is a system driver that is included in Windows. It is automatically loaded when you install a 1394 controller. This is not a redistributable driver that you can download separately.

I/O Request Completion

All I/O requests that are sent to the new 1394 bus driver return STATUS_PENDING because the 1394ohci.sys bus driver is implemented by using KMDF instead of WDM. This behavior differs from that of the legacy 1394 bus driver, in which certain I/O requests complete immediately.

A client driver must wait until I/O requests sent to the new 1394 bus driver are complete. You can provide an I/O completion routine that is called after the request is complete. The status of the completed I/O request is in the IRP.

Configuration ROM Retrieval

The new 1394 bus driver tries to use asynchronous block transactions at faster bus speeds to retrieve the contents of a node's configuration ROM. The legacy 1394 bus driver uses asynchronous quadlet reads at S100 speed—or 100 megabits per second (Mbps). The 1394ohci.sys bus driver also uses the values that are specified in generation and max_rom entries of the node's configuration ROM header to improve the retrieval of the remaining content of the configuration ROM. For more information about how the new 1394 bus driver retrieves the contents of a node's configuration ROM, see Retrieving the Contents of a IEEE 1394 Node's Configuration ROM.

IEEE-1394-1995 PHY Support

The 1394ohci.sys bus driver requires a physical layer (PHY) that supports IEEE-1394a or IEEE-1394b. It does not support a PHY that supports IEEE-1394-1995. This requirement is due to the 1394ohci.sys bus driver's exclusive use of short (arbitrated) bus resets.

1394 driver net adapter

NODE_DEVICE_EXTENSION Structure Usage

A client driver can reference the device extension in the 1394 bus driver associated with the physical device object (PDO) for the device that the client driver controls. This device extension is described by the NODE_DEVICE_EXTENSION structure. In 1394ohci.sys, this structure remains at the same location as in the legacy 1394 bus driver, but the nonstatic members of the structure might not be valid. When a client driver uses the new 1394 bus driver, they must make sure that the data accessed in NODE_DEVICE_EXTENSION is valid. The static members of NODE_DEVICE_EXTENSION that contain valid data are Tag, DeviceObject, and PortDeviceObject. All other members NODE_DEVICE_EXTENSION are nonstatic, which the client driver must not reference.

Gap Count Optimization

The default behavior of the 1394ohci.sys bus driver is to optimize the gap count when it finds only IEEE 1394a devices on the 1394 bus, excluding the local node. For example, if the system that is running 1394ohci.sys has a host controller that complies with IEEE 1394b but all devices on the bus comply with IEEE 1394a, then the new 1394 bus driver tries to optimize the gap count.

Gap count optimization occurs only if the 1394ohci.sys bus driver determines that the local node is the bus manager.

The 1394ohci.sys bus driver determines whether a device complies with IEEE-1394a by the speed setting in the node's self-id packet. If a node sets both of the bits in the speed (sp) field in the self-id packet, then 1394ohci.sys considers the node to comply with IEEE-1394b. If the speed field contains any other value, then 1394ohci.sys considers the node to comply with IEEE-1394a. The gap count value that is used is based on table E-1 in the IEEE-1394a specification, which provides the gap count as a function of hops. The 1394ohci.sys bus driver does not compute the gap count. You can change the default gap count behavior by using a registry value. For more information, see Modifying the Default Behavior of the IEEE 1394 Bus Driver.

1394 Driver Xp

Device Driver Interface (DDI) Changes

Sensable 1394 Driver License

Drivers abb oy. In Windows 7, the 1394 DDIs were changed to support faster speeds as defined by the 1394b specification and improved to simplify the development of 1394 client drivers. For more information about the general DDI changes that the new 1394 bus driver supports, see Device Driver Interface (DDI) Changes in Windows 7.

1394 Net Driver

Related topics

The IEEE 1394 Driver Stack
Retrieving the Contents of a IEEE 1394 Node's Configuration ROM

Sensible 1394 Driver Device

Last weekend I decided to dust off my Sensable Phantom Omni (nowthe3D Systems Geomagic Touch,but I bought mine before Geomagic bought Sensable and 3D Systemsbought Geomagic), and see if it was still usable. I had to orderaPCIe 1394b card,but other than that, I hooked it up, and the Phantom drivers seemed toinstall correctly on Windows 10. However, when running the Phantomdemo software, anytime a program tried to access the motors, theprogram would crash. Sensor reading seemed ok, but I couldn't get anyfeedback.

Sensible 1394 Driver Test

A quick call to the Geomagic Freeform support line turned up thesolution. As with many video products that used 1394b, the PhantomOmni requires the 'Legacy' firewire drivers. These were included withWindows up to Windows 7, but as of Windows 8 and above, are no longerincluded with the operating system.

After installing the drivers and changing the 1394 PCIe interface touse the Legacy drivers(process documented here),I rebooted and the demos worked fine, with force feedback and all!

Along the way, I also found some information on repairing internalcable breakage in the Omni, by a research team at John HopkinsUniversity. The original site had died, but the instructions andimages were stillavailableat this link via the Internet Archive.

Anyways, hope this helps others that still want to get some life outof their haptic controllers!
